UBIQUITI (POE-48-24W) POWER ADAPTER 48V 24W 0,5A
€17.00
Άμεσα Διαθέσιμο
Σε απόθεμα
Περιγραφή
These PoE Adapters are highly reliable and, in combination with the Ubiquiti TOUGHC cable, they provide grounding and surge protection to protect against electrostatic discharge (ESD).
Τεχνικά Χαρακτηριστικά
| Dimensions | 88 × 57 × 33 mm |
| Weight | 135.5 g |
| Output voltage | 48VDC @0.5A |
| LAN activity indicator | No |
| Gigabit LAN port | No |
| Remote resetting capability | No |
| Reset button | No |
| Input voltage | 90-260VAC @ 47-63 Hz |
| Input current | 0.6A @ 120VAC, 0.4A @ 240VAC |
| Inrush current | <60A Peak @120VAC, <120A Peak @ 230VAC |
| Effectiveness | 80+% |
| Output current pulsation | 1% Maximum |
| Switching frequency | 65 kHz |
| Linear adjustment | ± 1% |
| Load adjustment | ± 3% |
| 4-steam power supply | Pins 4, 5 (+) and Pins 7, 8 (-) |
| Operating temperature | 0 to 40° C |
| Storage temperature | -30 to 70°C |
| Humidity during operation | 35 to 95% |
| AC connector | IEC-320 C6 |
| Date IN / POE | RJ45 , shielded socket |
| Surge protection | Modes: Difference and Common |
| Clamp protections | 11 V Data, 60 V Power |
| Highest pulse rate | 36A (10/1000µS) Date |
| Electric capacity of the shunt | <5 pf date |
| Response time | <1 nS |
| Compatibility | IEC 60950-1:2005+A1 UL60950-1EN55022:2010, EN55024:2010 FCC Class B |
| AC cable with grounding | USA, EU, AR, BR, UL, CCC, Mexico |
Χρήσιμα Αρχεία
Επιπλέον πληροφορίες
| Βάρος | 80000.000 κ. |
|---|---|
| Διαστάσεις | 10 × 8 × 5 cm |
