Name: UBIQUITI (UACC-LRE) LONG-RANGE ETHERNET REPEATER (UP TO 1 KM LINK DISTANCES)
SKU: 018449
Availability: InStock

UBIQUITI (UACC-LRE) LONG-RANGE ETHERNET REPEATER (UP TO 1 KM LINK DISTANCES)

Κωδικός Προϊόντος: 018449

€42.00

Άμεσα Διαθέσιμο

Σε απόθεμα

Περιγραφή

Long-range Gigabit Ethernet adapter that receives PoE/PoE+ and offers passthrough PoE output.

Extend PoE connections up to 1 km*

(1) GbE RJ45 port for PoE/PoE+ input**

(1) GbE RJ45 port for passthrough PoE output

10kA+ surge protection

Works reliably in extreme temperatures (-40 to 80° C)

Τεχνικά Χαρακτηριστικά

Mechanical
Dimensions	196.5 x 93.5 x 39 mm ( 7.7 x 3.7 x 1.5″)
Weight	350 g (12.3 oz)
Enclosure material	UV stabilized polycarbonate
Mounting material	Stainless steel
Weatherproofing	IPX5
Hardware
Networking interface	(2) GbE RJ45 ports
PoE interface	(1) Passthrough PoE output 2-pairs (pins 1,2+; 3,6- )
Total non-blocking line rate	2 Gbps
Switching capacity	4 Gbps
Forwarding rate	1.488 Mpps
Power method	PoE/PoE+ 2-pairs (Pins 1, 2+; 3, 6- )
Power supply	UniFi PoE switch
Max. power consumption	1.5W (Excluding PoE output)
Total available PoE	22.5W
Voltage range PoE mode	37—57V DC
ESD/EMP protection	Air/contact: ± 30kV
DC sparkover voltage	90V at 100V/s
Max. impulse sparkover voltage	700V at 1kV/μs
Discharge current	10kA+
Max. MTU	1,500 bytes
Ambient operating temperature	-40 to 80° C (-40 to 176° F)
Ambient operating humidity	10 to 95% noncondensing
Certifications	CE, FCC, IC
LEDs
System	Blue: power ON
Ethernet	Green: 1 Gbps Amber: 10/100 Mbps
PoE	Amber: passthrough PoE out

Χρήσιμα Αρχεία

Datasheet:

Επιπλέον πληροφορίες

Βάρος	0.500 κ.
Διαστάσεις	20 × 10 × 8 cm

Κωδικός προϊόντος: 018449 Κατηγορία: Διάφορα Δικτύου
